Product Specifications

1238888

This chapter contains the Gage Max technical specifications and rated conditions for operation. For other Gage Max models, please consult the original User Manual that shipped with your FARO Gage Max or contact FARO Customer Service by Phone, Fax or Technical Support.



FARO Gage Max

Model 41000

Size	L1	L2	Weight
1.5M length	398 mm 15.7 in	213 mm 8.4 in	9.1 kg 20.05 lb



Size	A	B	C	Shipping Weight
Shipping Case 1.5M length	116.8 cm 46.0 in	43.1 cm 17.0 in	33 cm 13.0 in	28.6 kg 63.0 lb



Gage Max Rated Conditions
Operating Temperature Range	10°C to 40°C 50°F to 104°F
Storage Temperature Range	-20°C to 70°C -4°F to 122°F
Temperature Rate	3°C/5min 5.4°F/5min
Operating Humidity	Minimum 0% RH, Maximum 95% RH
Storage Humidity	Minimum 0% RH, Maximum 100% RH
Barometric Pressure Range	Minimum 225.50 mmHG, 8.878 inHG Maximum 825.07 mmHG, 32.483 inHG
Power Supply	Universal worldwide voltage 100-240 VAC, 47 to 63 Hz
