Product Specifications

1238888

This chapter contains the Gage technical specifications and rated conditions for operation. For other Gage models, please consult the original User Manual that shipped with your FARO Gage or contact FARO Customer Service by Phone, Fax or Technical Support.

FARO Gage

Model

Size

L1

L2

Weight

1.5M length



398 mm

15.7 in

213 mm

8.4 in

8.1 kg

17.9 lb



Size

A

B

C

Shipping
Weight

Shipping Case

1.5M length





114.5cm

45.1 in



40.9cm

16.1 in



33cm

13.0 in



26.0 kg

57.3 lb



Gage Rated Conditions

Operating Temperature Range



10°C to 40°C

50°F to 104°F

Storage Temperature Range

-20°C to 70°C

-4°F to 122°F

Temperature Rate

3°C/5min

5.4°F/5min

Operating Humidity

Minimum 0% RH, Maximum 95% RH

Storage Humidity

Minimum 0% RH, Maximum 100% RH

Barometric Pressure Range

Minimum

225.50mmHG, 8.878inHG

Maximum

825.07mmHG, 32.483inHG

Power Supply

Universal worldwide voltage
100-240VAC, 47 to 63Hz
