Holding the FARO Laser Line Probe

1238888

Never grab the FARO Laser Line Probe while measuring. Simply hold the pistol grip.

Avoid touching the lenses. When necessary, clean the left and right lenses with the cloth from the LLP case. Dirt and grease on either lens can cause poor results.

Pointing to a Surface

The following figure shows the orientation of the FARO Laser Line Probe to the surface.

① BlueLaser Line Beam ② Red Range Cross Hair ③ Camera Field of View (FOV)

Scanning a Surface
