Product Specifications

1238888

This chapter contains the Quantum Max technical specifications and rated conditions for operation. For other FaroArm models, please consult the original User Manual that shipped with your FARO FaroArm or contact FARO Customer Service by Phone, Fax or Technical Support.

FaroArm Quantum Max

Model 41000

Size	L1	L2	Weight 6-Axis	Weight 7-Axis
Quantum Max 1.5M length	398 mm 15.7 in	213 mm 8.4 in	8.1 kg 17.9 lb	N/A
2.5M length	629 mm 24.8 in	444 mm 17.5 in	8.5 kg 18.7 lb	8.8 kg 19.4 lb
3.0M length	755 mm 29.7 in	569 mm 22.4 in	8.8 kg 19.4 lb	9.0 kg 19.8 lb
3.5M length	879 mm 34.6 in	694 mm 27.3 in	9.0 kg 19.8 lb	9.2 kg 20.3 lb
4.0M length	1004 mm 39.5 in	819 mm 32.2 in	9.2 kg 20.3 lb	9.5 kg 20.9 lb

Size

Weight
6-Axis

Weight
7-Axis

Quantum Max

1.5M length

398 mm

15.7 in

213 mm

8.4 in

8.1 kg

17.9 lb

N/A

2.5M length

629 mm

24.8 in

444 mm

17.5 in

8.5 kg

18.7 lb

8.8 kg

19.4 lb

3.0M length

755 mm

29.7 in

569 mm

22.4 in

8.8 kg

19.4 lb

9.0 kg

19.8 lb

3.5M length

879 mm

34.6 in

694 mm

27.3 in

9.0 kg

19.8 lb

9.2 kg

20.3 lb

4.0M length

1004 mm

39.5 in

819 mm

32.2 in

9.2 kg

20.3 lb

9.5 kg

20.9 lb

Size 6-Axis	A	B	C	Shipping Weight
Quantum Max Shipping Case 1.5M length	114.5cm 45.1 in	40.9cm 16.1 in	33cm 13.0 in	26.0 kg 57.3 lb
2.5M length	114.5cm 45.1 in	40.9cm 16.1 in	33cm 13.0 in	27.1 kg 59.6 lb
3.0M length	149 cm 58.7 in	47.2 cm 18.6 in	26.9 cm 10.6 in	29.9 kg 65.9 lb
3.5M length	149 cm 58.7 in	47.2 cm 18.6 in	26.9 cm 10.6 in	30.2 kg 66.5 lb
4.0M length	149 cm 58.7 in	47.2 cm 18.6 in	26.9 cm 10.6 in	30.5 kg 67.2 lb

Size
6-Axis

Shipping
Weight

Quantum Max Shipping Case

1.5M length

114.5cm

45.1 in

40.9cm

16.1 in

33cm

13.0 in

26.0 kg

57.3 lb

2.5M length

114.5cm

45.1 in

40.9cm

16.1 in

33cm

13.0 in

27.1 kg

59.6 lb

3.0M length

149 cm

58.7 in

47.2 cm

18.6 in

26.9 cm

10.6 in

29.9 kg

65.9 lb

3.5M length

149 cm

58.7 in

47.2 cm

18.6 in

26.9 cm

10.6 in

30.2 kg

66.5 lb

4.0M length

149 cm

58.7 in

47.2 cm

18.6 in

26.9 cm

10.6 in

30.5 kg

67.2 lb

Size 7-Axis	A	B	C	Shipping Weight
Quantum Max Shipping Case 2.5M length	114.5cm 45.1 in	40.9cm 16.1 in	33cm 13.0 in	27.2 kg 59.9 lb
3.0M length	149 cm 58.7 in	47.2 cm 18.6 in	26.9 cm 10.6 in	30.0 kg 66.1 lb
3.5M length	149 cm 58.7 in	47.2 cm 18.6 in	26.9 cm 10.6 in	30.3 kg 66.8 lb
4.0M length	149 cm 58.7 in	47.2 cm 18.6 in	26.9 cm 10.6 in	30.6 kg 67.5 lb

Size
7-Axis

Shipping
Weight

Quantum Max Shipping Case

2.5M length

114.5cm

45.1 in

40.9cm

16.1 in

33cm

13.0 in

27.2 kg

59.9 lb

3.0M length

149 cm

58.7 in

47.2 cm

18.6 in

26.9 cm

10.6 in

30.0 kg

66.1 lb

3.5M length

149 cm

58.7 in

47.2 cm

18.6 in

26.9 cm

10.6 in

30.3 kg

66.8 lb

4.0M length

149 cm

58.7 in

47.2 cm

18.6 in

26.9 cm

10.6 in

30.6 kg

67.5 lb

Size	A	B	C	Weight
FARO Laser Line Probe	190 mm 7.5 in	177 mm 7.0 in	133 mm 5.2 in	0.5 kg 1.1 lb

Size

Weight

FARO Laser Line Probe

190 mm

7.5 in

177 mm

7.0 in

133 mm

5.2 in

0.5 kg

1.1 lb

Size	A	B	C	Shipping Weight
FARO Laser Line Probe Shipping Case	29.7 cm 11.7 in	23.1 cm 9.1 in	16.5 cm 6.5 in	1.9 kg 4.1 lb

Size

Shipping
Weight

FARO Laser Line Probe Shipping Case

29.7 cm

11.7 in

23.1 cm

9.1 in

16.5 cm

6.5 in

1.9 kg

4.1 lb

Size	A	B	Shipping Weight
8-Axis	25.0 cm 9.8 in	23.0cm 9.0 in	4.5 kg 10.0 lb

Size

Shipping
Weight

8-Axis

25.0 cm

9.8 in

23.0cm

9.0 in

4.5 kg

10.0 lb

Size	A	B	C	Shipping Weight
Shipping Case 8-Axis	45.5cm 17.9 in	34.0cm 13.4 in	17.5cm 6.9 in	9.6 kg 21.0 lb

Size

Shipping
Weight

Shipping Case

8-Axis

45.5cm

17.9 in

34.0cm

13.4 in

17.5cm

6.9 in

9.6 kg

21.0 lb

Quantum Max Rated Conditions
Operating Temperature Range	10°C to 40°C 50°F to 104°F
Storage Temperature Range	-20°C to 70°C -4°F to 122°F
Temperature Rate	3°C/5min 5.4°F/5min
Operating Humidity	Minimum 0% RH, Maximum 95% RH
Storage Humidity	Minimum 0% RH, Maximum 100% RH
Barometric Pressure Range	Minimum 225.50mmHG, 8.878inHG Maximum 825.07mmHG, 32.483inHG
Power Supply	Universal worldwide voltage 100-240VAC, 47 to 63Hz

FARO Blu^HD Laser Line Probe Specifications and Accuracy
Accuracy	±25μm (±0.0010 in)
Repeatability	25μm, 2σ (0.0010 in)
Stand-off	115mm (4.5in)
Depth of Field	115mm (4.5in)
Effective Scan width	Near Field 80mm (3.1in) Far Field 150mm (5.9in)
Points per Line	Maximum 4,000 points/line
Minimum Point Spacing	20μm (.0008in)
Point Acquisition Rate	Up to 1.2 million points per second
Laser	Class 2

FARO Blu^SD Laser Line Probe Specifications and Accuracy
Accuracy	±25μm (±0.0010 in)
Repeatability	25μm, 2σ (0.0010 in)
Stand-off	115mm (4.5in)
Depth of Field	115mm (4.5in)
Effective Scan width	Near Field 80mm (3.1in) Far Field 150mm (5.9in)
Points per Line	1,000
Minimum Point Spacing	80μm (.0031in)
Scan Rate	120frames/second 120fps x 1,000points/line = 120,000points/sec
Laser	Class 2

FARO Prizm Laser Line Probe - Scan Points with Color Values Specifications and Accuracy
Accuracy	±30μm (±0.0011 in)
Repeatability	30μm, 2σ (0.0011in)
Stand-off	115mm (4.5in)
Depth of Field	115mm (4.5in)
Effective Scan width	Near Field 80mm (3.1in) Far Field 150mm (5.9in)
Points per Line	2,000
Minimum Point Spacing	40μm (.0015in)
Scan Rate	120frames/second 120fps x 2,000points/line = 240,000points/sec
Laser	Class 2

FARO Prizm Laser Line Probe - Scan Points Only Specifications and Accuracy
Accuracy	±30μm (±0.0011 in)
Repeatability	30μm, 2σ (0.0011in)
Stand-off	115mm (4.5in)
Depth of Field	115mm (4.5in)
Effective Scan width	Near Field 80mm (3.1in) Far Field 150mm (5.9in)
Points per Line	2,000
Minimum Point Spacing	40μm (.0015in)
Scan Rate	300frames/second 300fps x 2,000points/line = 600,000points/sec
Laser	Class 2
